Deposition

Atomica’s wide variety of deposition tools and experience opens up our unparalleled material toolbox. This material flexibility gives us the power to accommodate and address electrical, mechanical and thermal constraints.

Atomica’s proficiency in handling a wide variety of materials provides the versatility needed for the development of MEMS, sensors, photonics, and biochips. Our solutions are tailored to meet diverse functional, structural, and electrical requirements while considering temperature limitations and backend assembly constraints. We specialize in comprehensive material deposition services, ranging from thin to thick films, utilizing advanced vacuum deposition techniques to ensure optimal performance for your device.

Atomica’s Deposition Capabilities

Atomica has a whole host of different targets under vacuum in multiple production-class cluster tools, from RF and DC magnetron systems to evaporators, LPCVD, and PECVD. WE offer the following capabilities:

  • Physical Vapor Deposition (PVD) PVD is a vacuum-based deposition method where material is vaporized from a solid source and deposited as a thin film onto a substrate. Common PVD techniques include sputtering and evaporation, where material is either ejected by ion bombardment or vaporized through heating.Chemical Vapor Deposition (CVD) CVD involves the chemical reaction of gaseous precursors that decompose on a heated substrate, forming a solid material. It allows precise control over film composition and thickness.
  • Plasma Enhanced Chemical Vapor Disposition PECVD enhances the traditional CVD process by using plasma to activate chemical reactions at lower temperatures, allowing for deposition on temperature-sensitive substrates.
  • Low Pressure Chemical Vapor Deposition (LPCVD) LPCVD is a variant of CVD performed under low pressure, promoting uniform film deposition over large surface areas. It offers excellent step coverage and is often used in high-temperature processes.
  • High Plasma Density CVD (HDPCVD) HDPCVD uses a high-density plasma to enhance the deposition process, allowing for excellent gap-filling and conformal coverage, particularly useful in high-aspect-ratio structures.
  • Atomic Layer Deposition (ALD)  ALD is a precise thin-film deposition technique where films are grown one atomic layer at a time. It alternates between two precursor gases, each reacting with the substrate to form a monolayer, allowing for atomic-scale thickness control.9
  • Ion beam deposition (IBD) IBD uses an ion beam to sputter material from a target, which is then deposited onto a substrate. The ion beam can also be used to modify film properties or clean the substrate prior to deposition.
  • E-Beam Evaporation E-beam evaporation is a physical vapor deposition technique where an electron beam is used to heat and vaporize material in a vacuum. The vaporized material then condenses onto a substrate to form a thin film.
  • Thermal Oxidation Thermal oxidation is the process of forming silicon dioxide (SiO2) by exposing silicon wafers to oxygen or steam at high temperatures. This oxidation process creates a high-quality insulating layer on the silicon surface.

For more details on our deposition capabilities, please contact our technical team or download our fab technology guide.
